Raising elephants on a ThinkPad T42 and an EeePC 701

A magic key

If you look at your computer keyboard, you probably have a key labelled SysRq somewhere, either on its own or as a secondary function of another key such as PrtSc. You probably never use it but if you run Linux, it's a magic key that enables you to perform low level commands even when the computer is completely stuck. A particularly useful combination of such commands uses the mnemonic Raising Elephants Is So Utterly Boring.

Finding SysRq

That's the theory. In practice, it can be difficult to find out what exact key combination triggers SysRq on your particular computer and whether you need to press SysRq and the command key at the same time or whether you can press SysRq first, release and then press the command key. To find out, switch to a text virtual terminal, by pressing Ctrl+Alt+F1. You will then be presented with a full screen black console with a login prompt. Don't worry, you can switch back to your normal screen by pressing Ctrl+Alt+F7 at any time. Log in with your user name and password. For this to work, we first need to check that support for SysRq is compiled in your kernel. To do this, enter the following command:

$ cat /boot/config-`uname -r` | grep CONFIG_MAGIC_SYSRQ
CONFIG_MAGIC_SYSRQ=y

If the result is as shown above, SysRq is compiled in your kernel. Next, we need to make sure it's enabled:

$ cat /proc/sys/kernel/sysrq
1

If it is enabled, you should get 1 as an answer. If you get 0, it's not enabled, if you get anything else, it's partially enabled. The full list of values can be found in the sysrq.c documentation. If it all enabled, it should be possible to try it out by sending a command directly to the SysRq trigger:

$ sudo su -
$ echo h > /proc/sysrq-trigger

You need to be root to do this, hence the sudo su - to start with. When you do this, you should see the SysRq held text printed out to the console. After that, revert to your own user immediately to avoid any risk of doing something bad to your computer: root is very powerful and it's therefore very easy to do something bad by accident. So type this command to revert to your own user:

$ exit

Now it's a case of trying all possible key combination with the h command to find out what your SysRq key is. If you have a full SysRq key, typing Alt+SysRq+h should display the same help message as above. If that's the case, you're done. Otherwise try any number of combinations of the keys Shift, Ctrl, Alt, AltGr or Fn with one of the keys SysRq, PrtSc, Insert, Delete, ScrLk and key h until you find what combination produces the help message. Once you've found it, log out by typing exit and revert to your standard virtual terminal by pressing Ctrl+Alt+F7

SysRq on a ThinkPad T42 and an EeePC 701

On my IBM ThinkPad T42, the SysRq key combination is AltGr+PrtSc so to get the help text, I would do AltGr+PrtSc+h. On my EeePC 701, the combination is Fn+Alt+Del, which means I have to press four keys at the same time to get the SysRq help text: Fn+Alt+Del+h! Luckily it's a small keyboard. On both machines, I have to press all 3 or 4 keys at the same time.

Improving your Linux Skills

I came across a few interesting web sites that are excellent resources if you want to improve your Linux skills:

• Tux Training is a generic resource on everything Linux. It's got some very good articles. I may contribute some of my own when I have the time;
• If you want to learn the basics of the command line and some basic bash programming, LinuxCommand.org is an excellent resource;
• If you are interested in programming, there is a good bash programming introduction at The Linux Documentation Project;
• Once you know the basics, TLDP also has an advanced bash programming guide to take you to the guru level.

Making Noise with ImageMagick

The Case for Noise

At the @media conference earlier this year, Dan Rubin presented a talk entitled Designing Virtual Realism where he explained that we should try to reproduce real life textures when designing web sites to produce the feel bit in look & feel. If you are as useless with Photoshop or GIMP as I am, it is quite a difficult feat. However, Dan also had advice for visual design challenged people like me: if you do nothing else, at the very least, add noise. What he meant by that is to replace flat background colours with something that is not quite flat, adding subtle noise to the colour. As usual, ImageMagick is a great tool for that sort of things and gives you the opportunity to automate it.

Creating Noise

ImageMagick has an option to create random noise, which makes it very easy to start. Enter the following in a terminal window:

$ convert -size 100x100 xc: +noise Random noise.png

This will produce a PNG image 100 pixels wide by 100 pixels tall that will look something like this:


Note that because the pixels in this image are completely random, it can be tiled, which is important if we want to use the final image as a tiled background.

Blurring the Noise

Next we need to blur the noise and desaturate it so that we can use it as a mask.

$ convert noise.png -virtual-pixel tile \
 -blur 0x1 -fx intensity -normalize noise-mask.png

Let's decompose this command to understand all the options:

-virtual-pixel tile

tells ImageMagick to use a tile of the picture for virtual pixels that are outside of the boundaries of the original. This is necessary because the blur algorithm uses neighbouring pixels to calculate a given colour. Using that option ensures that the result of the blur can also be used as a tile.

-blur 0x1

applies a fine blur to the image.

-fx intensity

selects the intensity channel only thus desaturating the image.

-normalize

stretches the contrast to ensure we go from pure black to pure white rather than average greys.

And here is the result:


Plain Colour Tiles

We then need two plain colour tiles that will be combined into the final image. Both colours should be very close to one another so that the noise is perceivable but not distracting. In this example, I will use two shades of red:

$ convert -size 100x100 xc:white -fill '#cc0000' -opaque white red1.png
$ convert -size 100x100 xc:white -fill '#bb0000' -opaque white red2.png

This is a rather weird syntax so let's explain it:

-size 100x100

creates an image that is 100x100 pixels.

xc:white

uses a pseudo-image that is completely white as a source image.

-fill '#cc0000'

selects the fill colour to be used by any following option, in this case a shade of red.

-opaque white

replaces all white pixels in the image (in this case the whole image) with the fill colour (red).

That's a bit convoluted but I haven't found a way to specify a hex colour value directly after xc:. If anybody knows better, please tell me.

Applying the Mask

The last step is to apply the mask created earlier to mix the two colour tiles:

$ convert red1.png red2.png noise-mask.png -composite red-noise.png

Et voilà! Some noise added to our plain red. And here is how the two compare, plain red on the left, noisy red on the right:

Plain Red vs Noisy Red

The difference is subtle but enough to give an impression of texture.

Script It

Last but not least, let's transform all of the above in a small shell script to be re-used later. Note that I am using bash here, which will work fine on Ubuntu or Mac OS-X but you may need to adapt it if you are using a different operating system:

noise.sh

#!/bin/bash

# Retrieve parameters and assign defaults if not found
size=${1:-50x50}
col1=${2:-#000000}
col2=${3:-#111111}
ofile=${4:-noise.png}

# Set the name of the temporary mask file
mask=/tmp/$$-mask.png

# Create temporary mask
convert -size $size xc: +noise Random -virtual-pixel tile\
        -blur 0x1 -fx intensity -normalize $mask

# Create both colours and compose with mask
convert -size $size xc:white -fill $col1 -opaque white\
        -size $size xc:white -fill $col2 -opaque white\
        $mask -composite $ofile

# Delete temporary file
rm $mask

To use it, you need to make it executable first:

$ chmod +x noise.sh

Then it's just a case of giving it a size, two colours and an output file name as parameters:

$ ./noise.sh 100x100 '#00cc00' '#00bb00' green-noise.png

Now, go make some noise and banish those boring plain backgrounds!

Fractals with Octave: Burning Ship

The story so far

• Classic Mandelbrot and Julia
• More on the Classic Sets
• Other Polynomials
• Trigonometric and Exponential Functions

After a long pause, here is the fifth instalment of this series on fractals with Octave. This time I will look at a fractal called the Burning Ship because of its output that looks like a ship going up in flames.

Burning Ship

The fractal is a Mandelbrot set that has a generating series defined by:

z_n+1=(|Re(z_n)|+i|Im(z_n)|)²+c

where the Re and Im are the functions that return the real and imaginary parts of a complex number. The initial condition is:

z₀=0

This fractal can be directly produced with the mandelbrot function we created in previous articles. In addition, we will take r=200 as a divergence limit.

octave-3.0.1:1> Mbs=mandelbrot(-2.5-2i,1.5+i,320,64,
> @(z,c) (abs(real(z))+i*abs(imag(z))).^2.+c,200);
octave-3.0.1:2> imagesc(Mbs)

Octave should open the Gnuplot window and display an image similar to this:

Burning Ship

Now let's zoom on this fractal centre left by a factor of 30:

octave-3.0.1:1> Mbsz=mandelbrot(-1.8-0.06i,-1.7+0.02i,320,64,
> @(z,c) (abs(real(z))+i*abs(imag(z))).^2.+c,200);
octave-3.0.1:2> imagesc(Mbsz)

Octave should open the Gnuplot window and display an image similar to this:

Burning Ship, left centre zoom x30

As usual with a fractal like this, the zoomed image looks very similar to the original. Now let's have a look at a related fractal called the Bird of Prey.

Bird of Prey

In the same way that you can produce interesting variations on the classic Mandelbrot set by changing the power used in the series, we can do the same with the Burning Ship series. So let's increase the power in the series above from 2 to 3:

z_n+1=(|Re(z_n)|+i|Im(z_n)|)³+c

This cubic series produces a fractal called the Bird of Prey.

octave-3.0.1:1> Mbs3=mandelbrot(-1.5-1.5i,1.5+1.5i,320,64,
> @(z,c) (abs(real(z))+i*abs(imag(z))).^3.+c,200);
octave-3.0.1:2> imagesc(Mbs3)

You'll note that I chose the boundary values for the complex plane so that I would get a square image centered on the origin. Here is the resulting image:

Bird of Prey

Next

That's it for the Burning Ship. Next in this series, we will look at the original fractal that Gaston Julia was interested in.

Selective Colouring with ImageMagick

Following a recent Photojojo newsletter, I thought I would do some experimentation with black and white. But rather than use Photoshop or GIMP, I decided to use ImageMagick: the command line may seem like more effort at first but it gives more control and you can also put everything in a script for later re-use.

Choosing a good photograph

There are some photographs that come out great as black and white, others that don't. Generally, the best candidates are the ones that look a bit uninteresting in colour, generally because there isn't much colour in them to start with. It's easy to get that sort of shots in London: just go out on a cloudy day and you'll get likely candidates. And so, I shot this picture on Sunday afternoon while on the South Bank:

The Globe Theatre

Although the building is nice, the picture itself is quite dull: there is little colour in it apart from the red flags so it's an ideal candidate for black and white treatment.

Separating the channels

Following the Photojojo article, rather than transform that photograph into grey scale, I started by separating the red, green and blue channels, which is very easy to do with ImageMagick:

$ convert img.jpg -separate img_rgb_%d.jpg

Assuming your original image is called img.jpg, this will produce three images called img_rgb_0.jpg, img_rgb_1.jpg and img_rgb_2.jpg that correspond to the red, green and blue channels respectively:

Red, green and blue channels

The last one, the blue channel, is the best black and white in my opinion as it's got the strongest shadows and lightest sky. Having said that, the red flags in the original photograph were the main spots of bright colour and it would be interesting to bring them back in the black and white shot through selective colouring. So let's do that.

Creating a mask

To selectively colour the flags red in the black and white picture, I am going to combine the original shot with the blue channel image. For this, I need to create a mask that will tell ImageMagick what part of the original shot to use and what part of the blue channel image to use. For the mask, I need a black and white picture that is white where the flags are and black everywhere else: this way, I can tell ImageMagick to use pixels from the original image where the mask is white and pixels from the blue channel image where the mask is black.

Because the flags are red, the idea is to find all the pixels in the original image that are red and no other colour. We can do that by combining the three channel images. Pixels that are a shade of grey, anywhere between black and white will show as the same shade of grey on all three channels but pixels that are of a specific colour, such as red, will be of a light grey in their primary channel and very dark in the other two. Indeed, if you look at the three channel images, the flags show as very light in the red channel but nearly black in the other two. So to create our mask, we can subtract the green and blue channels from the red one.

First, let's subtract the green channel from the red one:

$ convert img_rgb_1.jpg img_rgb_0.jpg -compose minus \
 -composite img_rgb_0-1.jpg

Which produces the following image:

Green channel subtracted from the red one

We can already see the flags pop out of the picture but we can also still see the outline of the theatre. So let's subtract the blue channel from the image we just obtained:

$ convert img_rgb_2.jpg img_rgb_0-1.jpg -compose minus \
 -composite img_rgb_0-1-2.jpg

Green and blue channels subtracted from the red one

That looks good, except that the flags are now light grey rather than really white. It is still a good mask but as the grey pixels will mix both images we use, it will dilute the effect. To ensure that we have a full effect, we need to stretch the contract of the mask to have the background area really black and the flags area really white.

$ convert img_rgb_0-1-2.jpg -level 10%,30% img_mask.jpg

The values given after the -level option specify the percentage of white under which a pixel is considered black first followed by the percentage of white over which a pixel is considered white. There is no real perfect value for those so you need to experiment. In this example, the second value is quite low because we really want most grey pixels to be turned white for a sharp mask.

Stretched mask

You will note that there are some small dots of white at the bottom of the mask. That's slightly unexpected but we'll see in a minute what they are.

Creating the final picture

Now that we have a mask, we need to combine the blue channel image with the original image by applying the mask. This is the simplest use of the -composite operator:

$ convert img_rgb_2.jpg img.jpg img_mask.jpg \
 -composite img_final.jpg

This produces the final image. We can now see that the small dots of white at the bottom of the mask have let out some of the colour of the red flowers on the lamppost, which is a nice extra touch and which would have been forgotten had we created the mask by hand with a drawing tool. Such side effects are typical of such a tool that works on the whole image and can be welcome or not depending on the situation. In any way, it is always possible to tweak the mask manually in a drawing tool before applying it.

Final image

Bootnote

The photo in its original size is now visible on flickr.

Fractals with Octave: Trigonometric and Exponential Functions

The story so far

• Classic Mandelbrot and Julia
• More on the Classic Sets
• Other Polynomials

In this fourth instalment of this series on fractals with Octave, I'll have a look at the Mandelbrot and Julia sets generated by non-polynomial series. Polynomials are fine but they can be a bit boring so what about introducing a sine or exponential in the mix? The original idea for this came from an excellent set of articles and examples by Paul Bourke.

Sine function

The first series we will use is defined thus:

z_n+1=c sin(z_n)

That's simple enough and very easy to code in Octave so as our mandelbrot and julia functions now have the ability to take a generating series as argument, it should be no problem. But before doing that, we need to know what value to give to r so that we know when the series diverges and when we can stop iterating. In the very first article, we saw that:

[...] for a given polynomial series, there exists a value r such that if for any n, |z_n|>r, then the series diverges.

This only applies to polynomials. The series above is not a polynomial series and its condition for divergence is that the imaginary part of z_n be greater than 50. That doesn't work well with our current code that expects a simple integer. We could replace the integer parameter expected by the mandelbrot and julia functions with a function handle but that would make their usage more complex when using polynomial series. Luckily, we can have the best of both worlds because Octave uses a weakly typed language: the type of a parameter passed to a function is not specified in the function definition, meaning that you can pass anything, you just have to hope that it is what the function expects. While this can be seen as a drawback for long and complex programs where validation can be cumbersome, it is actually a useful feature for a high level language like Octave where functions tend to be short. To make it work, we need to modify the mjcore function so that it can accept a function handle or an integer as its fifth parameter and act accordingly. For this, we will use the Octave isa built-in function to identify whether the parameter is a function handle. Here's how to modify the mjcore function:

mjcore.m

function M=mjcore(z,c,niter,f,r)
  if(isa(r,"function_handle"))
    rf=r;
  else
    rf=@(z) abs(z)<r;
  endif
  M=zeros(length(z(:,1)),length(z(1,:)));
  for s=1:niter
    mask=abs(z)<rrf(z);
    M(mask)=M(mask)+1;
    z(mask)=f(z(mask),c(mask));
  endfor
  M(mask)=0;
endfunction

That's all great and now we should be able to create our first sine Mandelbrot. We need to make sure that we reverse the comparison operator in the last parameter because our code is built so that we provide a convergence condition rather than a divergence one:

octave-3.0.1:1> Msin=mandelbrot(-1.2*pi+0.9*pi*i,1.2*pi-0.9*pi*i,
> 320,64,
> @(z,c) c.*sin(z), @(z) abs(imag(z))<=50);
octave-3.0.1:2> imagesc(Msin)

And we end up with... a dark blue rectangle, not quite what was expected. This is because in this form, the value of z₀ is 0, therefore sin(z₀) is also 0 and so is c sin(z₀): the series is always null and never diverges. To correct this, we would need to have z₀=c, that is initialise the series to the values of c. But if we do that in the code of the mandelbrot function, it will break some of our previous examples. That is unless we can specify a special value of z₀ to the mandelbrot function to force it to initialise to z₀=c. A similar trick to what we did for r above can do that: if the given parameter is the special string "c", initialise to c, otherwise assume the parameter is an integer and initialise as before. Here is the modified mandelbrot function:

mandelbrot.m

function M=mandelbrot(cmin,cmax,hpx,niter,
                      f=@(z,c) z.^2.+c,r=2,
                      z0=0)
  vpx=round(hpx*abs(imag(cmax-cmin)/real(cmax-cmin)));
  z=zeros(vpx,hpx).+z0;
  [cRe,cIm]=meshgrid(linspace(real(cmin),real(cmax),hpx),
                     linspace(imag(cmin),imag(cmax),vpx));
  c=cRe+i*cIm;
  if(strcmp("c",z0))
    z=c;
  else
    z=zeros(vpx,hpx).+z0;
  endif
  M=mjcore(z,c,niter,f,r);
endfunction

After that modification, we can run the mandelbrot function again with our new special parameter:

octave-3.0.1:1> Msin=mandelbrot(-1.2*pi+0.9*pi*i,1.2*pi-0.9*pi*i,
> 320,64,
> @(z,c) c.*sin(z), @(z) abs(imag(z))<=50, "c");
octave-3.0.1:2> imagesc(Msin)

Octave should open the Gnuplot window and display an image similar to this:

Sine Mandelbrot Set

We can also generate a sine Julia set without any change to the julia function:

octave-3.0.1:1> Jsin=julia(-2.4*pi+1.8*pi*i,2.4*pi-1.8*pi*i,
> 320,64,1+0.5i,
> @(z,c) c.*sin(z), @(z) abs(imag(z))<=50);
octave-3.0.1:2> imagesc(Jsin)

Sine Julia Set

Cool stuff! So let's have a look at other non-polynomial functions and their output.

Cosine

This series is defined by:

z_n+1=i c cos(z_n)

And has the same convergence condition than the previous series.

octave-3.0.1:1> Mcos=mandelbrot(-1.2*pi+0.9*pi*i,1.2*pi-0.9*pi*i,
> 320,64,
> @(z,c) i.*c.*cos(z), @(z) abs(imag(z))<=50, "c");
octave-3.0.1:2> imagesc(Mcos)

Cosine Mandelbrot Set

octave-3.0.1:1> Jcos=julia(-2.4*pi+1.8*pi*i,2.4*pi-1.8*pi*i,
> 320,64,0.55+1.195i,
> @(z,c) i.*c.*cos(z), @(z) abs(imag(z))<=50);
octave-3.0.1:2> imagesc(Jcos)

Cosine Julia Set

Tangent

This series is defined by:

z_n+1=c tan(z_n)

And uses the same convergence function as a polynomial with the default value of r.

octave-3.0.1:1> Mtan=mandelbrot(-1.4+1.4i,1.4-1.4i,
> 320,64,
> @(z,c) c.*tan(z), :, "c");
octave-3.0.1:2> imagesc(Mtan)

Tangent Mandelbrot Set

octave-3.0.1:1> Jtan=julia(-1.4+1.4i,1.4-1.4i,
> 320,64,(1+i)*sqrt(2)/2,
> @(z,c) c.*tan(z));
octave-3.0.1:2> imagesc(Jtan)

Tangent Julia Set

Exponential

First, let's multiply the exponential using the following series:

z_n+1=c exp(z_n²)

This series uses the default values for r and z₀.

octave-3.0.1:1> Mexp1=mandelbrot(-1.4+2i,1.4-2i,
> 240,64,
> @(z,c) c.*exp(z.^2));
octave-3.0.1:2> imagesc(Mexp1)

Exponential Mandelbrot Set #1

Then, let's add to the exponential using the following series:

z_n+1=exp(z_n²)+c

This series also uses the default values for r and z₀.

octave-3.0.1:1> Mexp2=mandelbrot(-2.2+2i,1-2i,
> 240,64,
> @(z,c) exp(z.^2).+c);
octave-3.0.1:2> imagesc(Mexp2)

Exponential Mandelbrot Set #2

Cactus

Finally, let's draw a cactus using the following series:

z_n+1=z_n³+(z₀-1)z_n-z₀

This series uses the default values for r and the special value z₀=c.

octave-3.0.1:1> Mcactus=mandelbrot(-0.8+0.6i,0.8-0.6i,
> 320,64,
> @(z,c) z.^3.+(c.-1).*z.-c,:,"c");
octave-3.0.1:2> imagesc(Mcactus)

Cactus Mandelbrot Set

Next

Next in this series, we will look at a fractal called the Burning Ship.

Lloyds TSB phishing scam

I just received an email which claims to come from Lloyds TSB. As I am not a customer of the bank, it is obviously a scam. I've been looking on the bank's web site in an attempt to report it to them but there doesn't seem to be any email address advertised where you can do so. There are a couple of telephone numbers for their customers but that's it. Surely, it would be useful to them to have copies of those emails, if only to know they exist and to warn their customers. But it seems they are not interested. Maybe it's a good thing I don't bank with them then.

Photos from Peru

I came back from Peru a week ago and spent a good part of last week tweaking and cleaning the best of them. They are now visible on flickr. The tweaking and cleaning I do on photos is very simple and consists in:

• stretching the contrast if required;
• removing fluff and dirt mark left on the lens or the sensor;
• very occasionally, cropping the shot.

So no heavy Photoshop (or in that instance GIMP) processing, just the bare minimum.

It's all relative

I'm in Peru. We just spent a couple of days around the Cañon de Colca, one of the deepest canyons in the world. The place where we stayed last night, Chivay, is at 3700 metres above sea level and on the way there we stopped at a viewpoint that was 4900 metres above sea level, higher than Mont Blanc. The area around Chivay and the canyon is lush and green and if it wasn't for the thin air, you'd easily forget that you are at an altitude that is higher than most of the Alps' ski resorts.

Nobody told the locals either, as explained by one of the girls in the group this morning: she asked the landlady of the hotel where she stayed overnight whether she kept llamas or alpacas, to which the landlady replied "we don't do that here, only in the mountains". That'd be the steep bits above 4000 metres that we see in the distance then.

Bootnote

This was written on the bus between Chivay and Puno yesterday and uploaded today.

ExifTool on Ubuntu

A while ago, I blogged about installing ExifTool on Ubuntu. There's actually a much simpler way to do this. ExifTool is part of the standard packages directly available from the Ubuntu repositories so it can be installed in one line using apt-get, no need for that make malarkey I mentioned last time:

$ sudo apt-get install libimage-exiftool-perl

Et voilà, ExifTool installed and ready to go!
